NVIDIA GeForce RTX 4070 Ti SUPER
nvidia
Brand8448
Cores16GB GDDR6X
Memory Size8448 : 264 : 96
Shaders/TMUs/ROPs256 Bit
Memory Bus672.3 GB/s
BandwidthBest Deals
NVIDIA GeForce RTX 4070 Ti SUPER
Techinical Specs
Overview
Manufacturer
nvidia
Release Date
2024
Launch Price
$ 799
GPU Name
AD103
GPU Varient
AD103-275-A1
Architecture
Ada Lovelace
Foundry
TSMC
Process Size
5 nm
Transistors
45900 mil
Performace
Pixel Rate
250.6 GPixel/s
Texture Rate
672.3 GPixel/s
FP16 Performance
44.1 TFLOPS
FP32 Performance
44.1 TFLOPS
FP64 Performance
689 GFLOPS
Memory
Memory Size
16 GB
Memory Type
GDDR6X
Memory Bus
256 bit
Bandwidth
672.3 GB/s
Features
DirectX
12.2
OpenGL
4.6
OpenCL
3
Vulkan
1.3
Shader Model
6.7
Render Config
Shading Units
8448
TMUs
264
ROPs
96
RT Cores
66
L1 Cache
128 KB
L2 Cache
48.00 MB
Design & Requirements
Memory Size
16 GB
Length
310 mm
Width
140 mm
TDP
285 W
Required PSU
600 W
Connection Outputs
1x 16-pin
Power Connectors
1x HDMI 2.1, 3x DisplayPort 1.4a
Simillar Performing GPUS
GeForce RTX 5070 Ti
2025
16 GB
GDDR7
$ 749
Radeon RX 9070 XT
2025
16 GB
GDDR6
$ 599
GeForce RTX 4080
2022
16 GB
GDDR6X
$ 1199
GeForce RTX 5080
2025
16 GB
GDDR7
$ 999
GeForce RTX 4070 SUPER
2024
12 GB
GDDR6X
$ 599
